Gabion cage

Gabion cage is a wire mesh cage that is cut and folded from heavy hexagonal nets. It is generally a cage assembled by folding and assembling 4 heavy hexagonal nets. Two small pieces of hexagonal mesh with a separator mesh in the middle. The cages of the gabion net can also be made into triangles and trapezoids. The dams stacked with such gabion net cages are inclined on a plane.

Gabion cages are often used as retaining walls in water conservancy projects. Gabion mesh retaining walls are retaining walls made of 0.5m-1.0m gabion cages. The gabion cage retaining wall is mainly used for steep hillsides, and its function is to control debris flow, prevent landslides, and protect the roadbed of roads and railways.

Material: hot-dip galvanized wire, electro-galvanized wire, hot-dip galvanized wire, zinc-aluminum alloy coated steel wire, etc.

Aperture: 6*8|7*9|8*10|9*11|10*12|11*13|12*15|14*18

Specifications: 2*1*1m, 3*1*1m, 4*1*1m, 2*1*0.5m, 4*1*0.5m.

Features of gabion cage:

(1) Economical, just put the stone into the cage and seal it. (2) The construction is simple and does not require special technology. (3) It has a strong ability to resist natural damage, corrosion resistance and harsh weather. (4) It can withstand a wide range of deformation without collapsing. (5) The silt between the gaps of the cage stones is conducive to plant production and can be integrated with the surrounding natural environment. (6) It has good permeability and can prevent damage caused by hydrostatic force. (7) Save transportation costs. It can be folded for transport and assembled on site.

Application of gabion cage:

(1) Control and guide rivers and floods; (2) Flood discharge dams and diversion dams; (3) Rockslide protection; (4) Prevention of soil erosion; (5) Bridge protection; (6) Soil solid structure; (7) coastal defense works; (8) port works; (9) retaining walls; (10) road protection;
