Concertina razor wire
Hot-dipped Galvanized Razor Wire Different coil diameter from 450mm to 980mm while the length and the diameter of the razor wire can be customized.
Keywords
Military defensive barrier
Category
Product Details
Blade Types for Galvanized Razor Wire: BTO-11, BTO-18, BTO-22, BTO-28, BTO-30, CBT-60, CBT-65 etc.
Hot-dipped Galvanized Razor Wire Different coil diameter from 450mm to 980mm while the length and the diameter of the razor wire can be customized.
Razor wire mesh are available the following materials:
Core Wire: Q195 Steel, Q235 Steel (Hot dipped Galvanized up to 275g/mm2, and the tensile strength can 1200Mpa) or Stainless Steel Wire in SS430、SS201 and SS304.
Barbed Tape: Hot dipped Galvanized Steel Sheet or Stainless Steel Sheet.
the razor wire specifiction :
|
Outer diameter |
No.of Loops |
Standard Length per Coil |
Type |
Notes |
|
450mm |
33 |
7M-8M |
CBT-65. 60 |
Single coil |
|
500mm |
41 |
10M |
CBT-65. 60 |
Single coil |
|
700mm |
41 |
10M |
CBT-65. 60 |
Single coil |
|
960mm |
54 |
11M-15M |
CBT-65. 60 |
Single coil |
|
500mm |
102 |
15M-18M |
BTO-11.18.22.28.30 |
Cross type |
|
600mm |
86 |
13M-16M |
BTO-11.18.22.28.30 |
Cross type |
|
700mm |
72 |
12M-15M |
BTO-11.18.22.28.30 |
Cross type |
|
800mm |
64 |
13M-15M |
BTO-11.18.22.28.30 |
Cross type |
|
960mm |
52 |
12M-15M |
BTO-11.18.22.28.30 |
Cross type |
the razor specifiction :
|
Reference Number |
Thickness mm |
Wire Diameter |
Blade Length |
Blade Width |
Blade Spacing |
|
BTO-11 |
0.5±0.05 |
2.5mm±0.1 |
10mm±1 |
15mm±1 |
26mm±1 |
|
BTO-18 |
0.5±0.05 |
2.5mm±0.1 |
18mm±1 |
15mm±1 |
33mm±1 |
|
BTO-22 |
0.5±0.05 |
2.5mm±0.1 |
22mm±1 |
15mm±1 |
33mm±1 |
|
BTO-28 |
0.5±0.05 |
2.5mm±0.1 |
28mm±1 |
15mm±1 |
33mm±1 |
|
BTO-30 |
0.5±0.05 |
2.5mm±0.1 |
30mm±1 |
18mm±1 |
45mm±1 |
|
CBT-60 |
0.6±0.05 |
2.5mm±0.1 |
60mm±2 |
32mm±1 |
100mm±1 |
|
CBT-65 |
0.6±0.05 |
2.5mm±0.1 |
65mm±2 |
22mm±1 |
100mm±1 |
